Product Details
＋
Inverters allow you to power domestic equipment - requiring 230V/120V AC - using 'leisure' or 'automotive' batteries rated at 12V, 24V or 48V DC.
VE.Direct communication port
The VE.Direct port can be connected to:
• A computer (VE.Direct to USB interface cable needed)
• Apple and Android smartphones, tablets, MacBook’s and other devices (VE.Direct Bluetooth Smart dongle needed)
Fully configurable
• Low battery voltage alarm trip and reset levels
• Low battery voltage cut-off and restart levels
• Dynamic cut-off: load dependent cut-off level
• Output voltage 210 - 245V
• Frequency 50 Hz or 60 Hz
• ECO mode on/off and ECO mode sense level
Monitoring
• In- and output voltage, % load and alarms
Specification
| Description | Phoenix 12/800 UK |
|---|---|
| Input Voltage | 9,2 - 17 / 18,4 - 34,0 / 36,8 - 62,0V |
| Voltage (V) | 12 |
| Watts | 650 |
| Length (mm) | 305 |
| Width (mm) | 216 |
| Height Inc Terminals (mm) | 105 |
| Weight | 5.5 |
| Continuous Output Power (VA) | 800 |
| Frequency (Hz) | 50Hz or 60Hz |
| Output Wave Form | Pure Sine Wave |
| Peak Power (W) | 1500 |
| Remote Control | Optional |
| Ingress Protection | IP21 |
| Warranty | 5 Years |
| VA | 800 |
| By Model | 12/800 |
